Rocker switch; ON-OFF, fixed, 2pins. 6A/250Vac, Ø19.8mm, SPST, round, waterproof, yellow
Product Code: KE/RO/Y/H
More similar products
Pickup at the LEMONA electronics store within 2 hours (if the item is in the store and the order is placed before 3 p.m.)
 6 pcs | Vilnius Žirmūnai Store |
| 2 pcs | Vilnius Naujamiestis Store |
| 5 pcs | Kaunas Store |
| 2 pcs | Klaipėda Store |
| 11 pcs | Šiauliai Store |
| 33 pcs | Central Warehouse (new location) |
Home delivery in Lithuania 1-2 b.d.
Delivery to pickup location 1-2 b.d.
Products purchased together
Delivery terms
Pickup In Store
Pickup In Store For free
Orders are processed and shipped on weekdays from 8:00 a.m. to 5:00 p.m.
When your order is ready for collection, we will inform you by SMS and e-mail.
Quantity in shop
| 6 pcs | Vilnius Žirmūnai Store |
| 2 pcs | Vilnius Naujamiestis Store |
| 5 pcs | Kaunas Store |
| 2 pcs | Klaipėda Store |
| 11 pcs | Šiauliai Store |
| 33 pcs | Central Warehouse (new location) |
Home delivery in Lithuania
Home delivery in Lithuania
After handing over the goods to the courier, we will inform you by e-mail. If you are ordering outside of Lithuania please use www.lemona-electronics.eu to order.
Over €30.00 (Orders up to 1000 kgs) | For free |
To €30.00 (Orders up to 3 kgs) | €2.99 |
To €30.00 (Orders up to 1000 kgs) | €3.59 |
Delivery to a DPD Pickup location
Delivery to a DPD Pickup location
After handing over the goods to the courier, we will inform you by e-mail. Orders over €30.00 are delivered free of charge.
€1.99
Product description
Weight
0.006 kg.
Technical data
| Rated current, voltage | 6A 250V AC |
| Contact resistance | ≤50mΩ |
| Insulation resistance | ≥100MΩ |
| Dielectric strength | 1500VAC/5s |
| Endurance | 50000 cycles |
| Ingress protection ratio | IP65 |
Specifications
SKU
328144
Weight
0.006 kg.
Fixation, 1-Su / 0-Be
With
Indication color
Yellow
Switch shape
Round
Connection type
ON-OFF
Key color
Yellow
Contact configuration
SPST
Number of contacts
2
Body color
Black
Width, mm
19.8
Current, A
6
Product code
KE/RO/Y/H
