Resistor network: Y; SMD; R: 270kΩ; ±5%; 62.5mW; No.of resistors: 4 ROYALOHM
Product Code: DR0804-270K-4/8
More similar products
Delivery terms
2024-11-29 Estimated delivery
Product will be ordered from supplier. If the supplier is unable to deliver by the specified date, we will inform you by e-mail
 8998 pcs | Supplier Warehouse |
Home delivery in Lithuania
Home delivery in Lithuania
After handing over the goods to the courier, we will inform you by e-mail. If you are ordering outside of Lithuania please use www.lemona-electronics.eu to order.
Over €50.00 (Orders up to 1000 kgs) | For free |
To €50.00 (Orders up to 3 kgs) | €3.49 |
To €50.00 (Orders up to 1000 kgs) | €4.99 |
Delivery to a DPD Pickup location
Delivery to a DPD Pickup location
After handing over the goods to the courier, we will inform you by e-mail. Orders over €50.00 are delivered free of charge.
€2.39
Product description
Resistor network: Y; SMD; R: 270kΩ; ±5%; 62.5mW; No.of resistors: 4 ROYALOHM
Useful information
Specifications
SKU
U-167277
Product code
DR0804-270K-4/8
Supplier product description
Resistor network: Y; SMD; R: 270kΩ; ±5%; 62.5mW; No.of resistors: 4
Useful information
Supplier parameters
Product code
DR0804-270K-4/8
Product ID
U-167277
Body dimensions
2x1x0.45mm
Case - inch
0804
Case - mm
2010
Manufacturer
ROYALOHM
Max. operating voltage
50V
Max. overload voltage
100V
Min. insulation resistance
1GΩ
Mounting
SMD
Number of resistors
4
Operating temperature
-55...125°C
Power
62.5mW
Resistance
270kΩ
Resistor features
terminals of all resistors are separated
Temperature coefficient
200ppm/°C
Terminal pitch
0.5mm
Type of resistor network
Y
Tolerance
±5%
Supplier's product code
DR0804-270K-4/8
The information that supplier provides may differ from the actual product. If you noticed an error please let us know by email: [email protected].
